5062000601 Coolant Pump. Listed in MTU 183 catalog references; confirm installation and current availability before ordering.
Check 5062000601 availability: Start with 5062000601 and the quantity. Add an engine serial number or a photo of the old Coolant Pump if available; we will follow up on any missing details.
5062000601 Specification
About 5062000601 - Coolant Pump
Published catalog details are identification references. They do not establish current stock, supplied condition, or confirmed fitment for your engine.
5062000601 is a coolant pump catalogued for MTU 183 engines. The catalog unit weight is 6.374 kg, which we use to estimate freight before quoting.
Technical Notes: Cooling system
The cooling system removes heat from the cylinder liners, cylinder heads, lube oil, and charge air. Marine MTU engines usually combine an engine coolant circuit with a seawater circuit through heat exchangers, while generator engines often use radiators. Coolant quality has a direct effect on liner cavitation and pump seal life.
Series 183 engines in marine service use a seawater pump and heat exchanger, while generator versions may be radiator-cooled, so cooling parts depend on the installation.
When This Type of Part Is Usually Replaced
- coolant leaks from the pump weep hole indicate seal wear
- engine temperature rises under load or fluctuates, pointing to thermostats or flow problems
- seawater pump impellers show cracked or missing vanes at inspection
Checks Before Ordering
- Replace thermostats and their seals together, and check the opening temperature on the replacement
- Seawater pump impellers should be kept as onboard spares for marine engines
- Flush and refill with an approved coolant after replacing pumps or heat-exchanger parts
Engine Catalog References
5062000601 is listed for 8 engine models in the catalog references. The specification table decodes each model code from the fitment list; it does not confirm every installation.
| Model | Cylinders | Arrangement | Application | Group / build |
|---|---|---|---|---|
| 8V 183 TE52 | 8 | V | marine | build 2 |
| 8V 183 AA51 | 8 | V | marine | build 1 |
| 6R 183 TD13H | 6 | In-line | — | build 3 |
| 12V 183 TE93 | 12 | V | marine | build 3 |
| 12V 183 TE52 | 12 | V | marine | build 2 |
| 12V 183 TD13 | 12 | V | — | build 3 |
| 12V 183 TB32 | 12 | V | generator sets | build 2 |
| 12V 183 TA12 | 12 | V | — | build 2 |
How Each Model Code Reads
- 8V 183 TE52: 8 cylinders in V arrangement, Series 183, turbocharged, charge-air code TE, application group 5 (marine), build 2
- 8V 183 AA51: 8 cylinders in V arrangement, Series 183, charging and cooling code AA, application group 5 (marine), build 1
- 6R 183 TD13H: 6 cylinders in line, Series 183, turbocharged, charge-air code TD, application group 1, build 3, rating variant H
- 12V 183 TE93: 12 cylinders in V arrangement, Series 183, turbocharged, charge-air code TE, application group 9 (marine), build 3
- 12V 183 TE52: 12 cylinders in V arrangement, Series 183, turbocharged, charge-air code TE, application group 5 (marine), build 2
- 12V 183 TD13: 12 cylinders in V arrangement, Series 183, turbocharged, charge-air code TD, application group 1, build 3
- 12V 183 TB32: 12 cylinders in V arrangement, Series 183, turbocharged, charge-air code TB, application group 3 (generator sets), build 2
- 12V 183 TA12: 12 cylinders in V arrangement, Series 183, turbocharged, charge-air code TA, application group 1, build 2
Full parts list for this model family: MTU 183 AA51 to TE93 Parts List
Engine-series references do not confirm every installation. Final fitment of 5062000601 depends on the full engine serial number and assembly position.
Common Replacement Scenarios
This part is commonly replaced when:
- coolant, seawater, fuel, or oil flow is weak or temperature is above normal range
- flange, port, drive, and installation variant must match the existing assembly
- scheduled marine or generator maintenance requires a verified replacement route
Usually Ordered with Coolant Pump
Pump overhauls usually renew the shaft seal, impeller, and housing seals together. These MTU 183 references are commonly checked in the same job; each still needs its own fitment check.
- 0000983080 Gasket
- 0049976548 O-Ring
- 007603014104 Sealing Ring
- 4420160420 Cylinder Head Gasket
- 8692040067 Impeller
Cross-Reference and Superseded Part Numbers
Catalog history distinguishes earlier and later numbers where documented. Reference-only entries do not establish replacement direction or interchangeability. Confirm the offered number against the engine serial number and installation.
| Part number | Catalog relationship |
|---|---|
| 5062000101 | Reference only; direction unconfirmed |
Common Applications
- Marine cooling systems
- Industrial radiator systems
- Generator cooling
Information to Send for Quotation
- Exact part number: 5062000601
- Part name or assembly position: Coolant Pump
- Engine model / series: MTU 183
- Engine serial number from nameplate
- Old-part photo showing number, connector, port, or size marking
- Required quantity and whether partial shipment is acceptable
- Destination country, delivery deadline, and preferred shipping method
The quotation confirms the offered part number, supply condition, price, lead time, and shipping options.
Ordering Notes
For 5062000601, send the engine model, serial number, quantity, old-part photo, and destination country. We will confirm whether the item is OEM, OEM-alternative, reman, or superseded before quotation.
5062000601 FAQ
Does 5062000601 fit MTU 183?
5062000601 Coolant Pump is checked against MTU 183. Final fitment depends on the engine serial number, rating, and installation position.
What information is needed to quote 5062000601?
Send the part number, engine model, engine serial number, old-part photo, quantity, destination country, and required delivery date. This lets us confirm stock route, packing, and shipping options.
Can you check alternatives or superseded numbers for 5062000601?
5062000601 may relate to 5062000101. Final replacement status is checked against the engine serial number before quote.
When is 5062000601 usually replaced?
coolant, seawater, fuel, or oil flow is weak or temperature is above normal range; flange, port, drive, and installation variant must match the existing assembly; scheduled marine or generator maintenance requires a verified replacement route.
Verification Notes
- Confirm engine model, serial number, required quantity, and destination before ordering.
- Send old part photos or nameplate details when markings or replacement status are unclear.
- Priority item: part number, supersession, and export packing details are checked before quote.
