5370550050 Bushing. Listed in MTU 396 catalog references; confirm installation and current availability before ordering.
Check 5370550050 availability: Start with 5370550050 and the quantity. Add an engine serial number or a photo of the old Bushing if available; we will follow up on any missing details.
5370550050 Specification
About 5370550050 - Bushing
Published catalog details are identification references. They do not establish current stock, supplied condition, or confirmed fitment for your engine.
5370550050 is a bushing catalogued for MTU 396 engines. The catalog unit weight is 0.066 kg, which we use to estimate freight before quoting.
Technical Notes: Bearings
Main and connecting-rod bearings support the crankshaft and run on a thin oil film. MTU bearings are supplied in size grades to suit original and reground crankshafts, so the size marked on the old shells or on the crankshaft record has to be known before ordering.
When This Type of Part Is Usually Replaced
- the engine reaches its major-overhaul interval
- oil analysis or filter inspection shows bearing material
- oil pressure loss or knocking points to bearing wear
Checks Before Ordering
- Confirm the size grade (for example size 0 or an undersize) from the old shells or crankshaft measurements
- Replace bearings as complete sets per crankshaft journal type
- Thrust bearings and washers should be checked together with the main bearings
Engine Catalog References
5370550050 is listed for 8 engine models in the catalog references. The specification table decodes each model code from the fitment list; it does not confirm every installation.
| Model | Cylinders | Arrangement | Application | Group / build |
|---|---|---|---|---|
| 12V 396 TC54 | 12 | V | marine | build 4 |
| 12V 396 TC64 | 12 | V | marine | build 4 |
| 12V 396 TE64 | 12 | V | marine | build 4 |
| 12V 396 TE74 | 12 | V | marine | build 4 |
| 12V 396 TE74L | 12 | V | marine | build 4 |
| 12V 396 TE84 | 12 | V | — | build 4 |
| 12V 396 TE94 | 12 | V | marine | build 4 |
| 12V 396 TB94 | 12 | V | marine | build 4 |
How Each Model Code Reads
- 12V 396 TC54: 12 cylinders in V arrangement, Series 396, turbocharged, charge-air code TC, application group 5 (marine), build 4
- 12V 396 TC64: 12 cylinders in V arrangement, Series 396, turbocharged, charge-air code TC, application group 6 (marine), build 4
- 12V 396 TE64: 12 cylinders in V arrangement, Series 396, turbocharged, charge-air code TE, application group 6 (marine), build 4
- 12V 396 TE74: 12 cylinders in V arrangement, Series 396, turbocharged, charge-air code TE, application group 7 (marine), build 4
- 12V 396 TE74L: 12 cylinders in V arrangement, Series 396, turbocharged, charge-air code TE, application group 7 (marine), build 4, increased rating (L)
- 12V 396 TE84: 12 cylinders in V arrangement, Series 396, turbocharged, charge-air code TE, application group 8, build 4
- 12V 396 TE94: 12 cylinders in V arrangement, Series 396, turbocharged, charge-air code TE, application group 9 (marine), build 4
- 12V 396 TB94: 12 cylinders in V arrangement, Series 396, turbocharged, charge-air code TB, application group 9 (marine), build 4
Full parts list for this model family: MTU 12V 396 TB94 to TE94 Parts List
Engine-series references do not confirm every installation. Final fitment of 5370550050 depends on the full engine serial number and assembly position.
Cross-Reference and Superseded Part Numbers
5370550050 has no public alternative number listed in our current data. We still check old-part photos, engine serial number, and catalog position for supersession before quotation.
Common Applications
- Engine overhaul
- Crankshaft service
- Marine and industrial engines
Information to Send for Quotation
- Part number: 5370550050
- Engine model, rating, and serial number
- Nameplate photo and old part photo when available
- Quantity, destination country, and required delivery date
The quotation confirms the offered part number, supply condition, price, lead time, and shipping options.
Verification Notes
- Confirm engine model, serial number, required quantity, and destination before ordering.
- Send old part photos or nameplate details when markings or replacement status are unclear.
