735038008106 Rubber Hose. Listed in MTU 538 catalog references; confirm installation and current availability before ordering.
Check 735038008106 availability: Start with 735038008106 and the quantity. Add an engine serial number or a photo of the old Rubber Hose if available; we will follow up on any missing details.
735038008106 Specification
About 735038008106 - Rubber Hose
Published catalog details are identification references. They do not establish current stock, supplied condition, or confirmed fitment for your engine.
735038008106 is a rubber hose catalogued for MTU 538 engines. It is the later number for 815M27703/1, 700160008115, 700160008719, 700160008202 and 7 more earlier references, so lists quoting those numbers are normally supplied as 735038008106. The catalog unit weight is 0.206 kg, which we use to estimate freight before quoting.
Technical Notes: Air and intake
The intake system delivers clean, cooled air to the cylinders. Leaks in hoses, charge-air pipes, or intercooler connections reduce charge pressure and raise exhaust temperatures, while damaged air filters let dust reach the turbocharger and cylinders.
When This Type of Part Is Usually Replaced
- charge-air hoses are cracked, swollen, or oil-soaked
- boost pressure drops and a leak is found on the charge-air side
- air-filter elements reach their restriction limit
Checks Before Ordering
- Replace hose clamps with the hoses on charge-air connections
- Check charge-air cooler connections for oil, which can indicate turbocharger seal problems
- Intake parts on marine engines may differ from generator versions of the same series
Engine Catalog References
735038008106 is listed for 10 engine models in the catalog references. The specification table decodes each model code from the fitment list; it does not confirm every installation.
| Model | Cylinders | Arrangement | Application | Group / build |
|---|---|---|---|---|
| 12V 538 TB92 | 12 | V | marine | build 2 |
| 20V 538 TB92 | 20 | V | marine | build 2 |
| 16V 538 TB93 | 16 | V | marine | build 3 |
| 20V 538 TB93 | 20 | V | marine | build 3 |
| 12V 538 TB8 | 12 | V | — | build TB |
| 12V 538 TB9 | 12 | V | — | build TB |
| 20V 538 TB1 | 20 | V | — | build TB |
| 20V 538 TB6 | 20 | V | — | build TB |
| 20V 538 TB7 | 20 | V | — | build TB |
| 16V 538 TB9 | 16 | V | — | build TB |
How Each Model Code Reads
- 12V 538 TB92: 12 cylinders in V arrangement, Series 538, turbocharged, charge-air code TB, application group 9 (marine), build 2
- 20V 538 TB92: 20 cylinders in V arrangement, Series 538, turbocharged, charge-air code TB, application group 9 (marine), build 2
- 16V 538 TB93: 16 cylinders in V arrangement, Series 538, turbocharged, charge-air code TB, application group 9 (marine), build 3
- 20V 538 TB93: 20 cylinders in V arrangement, Series 538, turbocharged, charge-air code TB, application group 9 (marine), build 3
- 12V 538 TB8: 12 cylinders in V arrangement, Series 538, single-digit build code TB
- 12V 538 TB9: 12 cylinders in V arrangement, Series 538, single-digit build code TB
- 20V 538 TB1: 20 cylinders in V arrangement, Series 538, single-digit build code TB
- 20V 538 TB6: 20 cylinders in V arrangement, Series 538, single-digit build code TB
- 20V 538 TB7: 20 cylinders in V arrangement, Series 538, single-digit build code TB
- 16V 538 TB9: 16 cylinders in V arrangement, Series 538, single-digit build code TB
Full parts list for this model family: MTU 538 TB1 to TB93 Parts List
Engine-series references do not confirm every installation. Final fitment of 735038008106 depends on the full engine serial number and assembly position.
Cross-Reference and Superseded Part Numbers
Catalog history distinguishes earlier and later numbers where documented. Reference-only entries do not establish replacement direction or interchangeability. Confirm the offered number against the engine serial number and installation.
| Part number | Catalog relationship |
|---|---|
| 815M27703/1 | Listed earlier number |
| 700160008115 | Listed earlier number |
| 700160008719 | Listed earlier number |
| 700160008202 | Listed earlier number |
| 700160008103 | Listed earlier number |
| 700160008718 | Listed earlier number |
| 124M21704/1 | Listed earlier number |
| 124M21703/1 | Listed earlier number |
| 114M21711/1 | Listed earlier number |
| 114M21709/1 | Listed earlier number |
| 735038008204 | Listed earlier number |
Common Applications
- Marine engine rooms
- Industrial sites
- Generator enclosures
Information to Send for Quotation
- Part number: 735038008106
- Engine model, rating, and serial number
- Nameplate photo and old part photo when available
- Quantity, destination country, and required delivery date
The quotation confirms the offered part number, supply condition, price, lead time, and shipping options.
735038008106 FAQ
Is 815M27703/1 replaced by 735038008106?
Catalog history lists 735038008106 as the later number for 815M27703/1, 700160008115, 700160008719, 700160008202, 700160008103, 700160008718, 124M21704/1, 124M21703/1, 114M21711/1, 114M21709/1, 735038008204. Orders quoting those numbers are normally supplied as 735038008106; we confirm the change against the engine serial number, because a later number can come with related changes to mating parts.
Verification Notes
- For 735038008106, confirm engine model, serial number, required quantity, and destination before ordering.
- If 735038008106 markings or replacement status are unclear, send old-part photos or nameplate details.
